Material attaches the liquid:
PP/TPV/Viton-F suitable for : Acid and alkaline chemical solution
PP/TPV/EPDM suitable for :Fleshwater
PP/TPV/NBR suitable for :Water
Featrures:
1.Self-Priming
2.Can run dry for long time
3.Suction:2.5-3M
4.Heat resistant 60°C
5.Can keep working for long time
| Voltage | Flow Rate | Head | Control Method | Max.Amps | Setting Pressure | Inlet/Outlet |
|---|---|---|---|---|---|---|
| DC 24V | 19.2LPM | 40M | Pressure switch | 20A | 0.5Mpa | 3/4" Pipe thread |
| DC 24V | 20.6LPM | 40M | Pressure switch | 10A | 0.5Mpa | 3/4" Pipe thread |
| DC 48V | 23 LPM | 40 M | Pressure switch | 5A | 0.5Mpa | 3/4" Pipe thread |
Filling machine |
Liquid transfer |
Cleanning or spraying |
