Material attaches the liquid:
PP/TPV/Viton-F suitable for : Acid and alkaline chemical solution
PP/TPV/Silicon suitable for :food grade liquid
PP/TPV/EPDM suitable for :Adblue
Featrures:
1.Self-Priming
2.Can run dry for long time
3.Suction:3M
4.Heat resistant 60°C
5.Can keep working for long time
| Voltage | Flow Rate | Head | Suction | Max.Amps | Setting Pressure | Inlet/Outlet |
|---|---|---|---|---|---|---|
| DC 12V | 12.6LPM | 100M | 25M | 7A | 1Mpa | 1/2" Pipe thread |
| DC 24V | 13.2LPM | 100M | 25M | 4A | 1Mpa | 1/2" Pipe thread |
| DC 48V | 13.2LPM | 100M | 25M | 2A | 1Mpa | 1/2" Pipe thread |
Filling machine |
Liquid transfer |
Cleanning or spraying |
